Everyone must know that the bag filter can not work with damaged bags, otherwise the filter will be easily scrapped.

If only a small part of an individual cloth bag is damaged, the broken hole can be repaired with worn cloth bag or bonded with silicone rubber mixture. If most cloth bags are damaged, they shall be replaced in time. It is better to replace the cloth bag after the dust collector stops working for 1 hour. Today, let's talk about how to change the cloth bag.

1. Open the top hatch cover of the dust collector.

2. Remove the spray pipe of the dust collector.

3. Pull up the grid.

4. Clean the garbage in the dust collector box.

5. Drill the filter bag into the flower plate hole. Put the bayonet flat to the flower plate hole, bend the bayonet inward, and align the bayonet groove with the flower plate hole. Adjust the bayonet position, press the bayonet to confirm the position to avoid the cloth bag falling off.

6. Put in the grid.

7. Install the spray pipe, tighten the fixing screw of the spray pipe, and align the outlet with the center of the cloth bag.

8. Put on the top cover, tighten the top cover screws. And the installation is completed.

The above steps are to replace the cloth bag. When purchasing the dust collector, we should consider the price, quality, after-sales and other aspects to select the appropriate dust collector equipment.
